1x1 Single Port 90 Degree 8P8C RJ45 Jack 10/100Base With Transformer Customized RJ45 With Transformer

Name: 1x1 Single Port 90 Degree 8P8C RJ45 Jack 10100Base With Transformer Customized RJ45 With Transformer
Brand: DGKYD
Price: 1 USD

Buy cheap 1x1 Single Port 90 Degree 8P8C RJ45 Jack 10/100Base With Transformer Customized RJ45 With Transformer product

Place of Origin : DongGuan of China

Brand Name : DGKYD

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

MOQ : 1 piece

Packaging Details : Tray in Carton

Delivery Time : 10 days

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 100K pcs/day

Model Number : KRJ-0042GYNL

Price : Please contact us to get the latest price.

SPEED : 100BASE-TX

LED OPTION : G/Y

CONTACT MATING AREA PLATING : GOLD 6 U''

PCB MOUNT ANGLE : SIDE ENTRY

Contact Now

Network 90 Degree RJ45 8P8C 10/100Base Tab Down Transformer

ATTRIBUTE	ATTRIBUTE VALUE
TEMPERATURE	-40 to +85℃
GROUNDING OPTIONS	Panel Ground and PCB Ground
SHIELD PLATING MATERIAL	NICKEL
SHIELD EMI TABS	YES
SHIELD	METAL SHIELD
ROHS COMPLIANT	YES
PANEL STOP	YES
PCB MOUNT ANGLE	SIDE ENTRY
PACKAGE	DIP
CONNECTOR & CONTACT TERMINAATES TO	Printed Circuit Board
NUMBER OF PORTS	1X1
NUMBER OF CONTACTS	8
LED OPTION	G/Y
LATCH ORIENTATION	LATCH DOWN
HOUSING MATERIAL	PBT UL94V-0
CONTACT MATING AREA PLATING	GOLD 6U'' PLATING
CONNECTOR TYPE	RJ45
CONNECTOR MATERIAL COLOR	BLACK

1x1 Single Port 90 Degree 8P8C RJ45 Jack 10/100Base With Transformer Customized RJ45 With Transformer

Applications:

• Integrated RJ45 connector main used to :

• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone, internet set-top box,internet camera,net bridge,computer,

telecommunication,MODEM,HomePNA,DSL／ADSL and so on.

Competitive Advantage:

Keyouda has various types of appearance and many kinds of internal schematic products,high quality,

customer firstly ,100% test, 0 defect, short lead time are our best advantages
