Name: Side Entry Shield PoE RJ45 Single Port Internal Magnetic ModuleUseage HR911102A
Brand: DGKYD
Price: 1 USD

Model Number : KRJ-803GYZENL

Place of Origin : DongGuan of China

Brand Name : DGKYD

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

MOQ : 1 piece

Packaging Details : Tray in Carton

Delivery Time : 10 days

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 100K pcs/day

Price : Please contact us to get the latest price.

Application : net card, fiber optic,ip camera ,dvr,dsl,modem,wifi etc

Feature : PoE RJ45

OEM/ODM : yes

Type : Multi pin rj45 magjack

Gender : rj45 receptacle

Product Name : RJ45 Modular Jack

Contact Now

Side Entry Shield 1X1 Tab-Down RJ45 Single port / Internal Magnetic Module With Led

Side Entry Shield PoE RJ45 Single Port / Internal Magnetic Module,Useage HR911102A

Available for 2.5GBASE-T, 5GBASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T, HDBASE-T Speeds
RoHS Compliant
Top and Side-Entry PCB Mount Options Available
Multiple Package Options Available, 1x1, 1xN, 2xN, RJ45/USB, Low Profile, Offset & more.
THT, Press Fit, Pin-In-Paste, SMT Options
Higher Isolation (TVSS, Surge)
Extended Temperature -40°C to +85°C
PoE, PoE+ & 4 Pair PoE Capable

RJ45 jacks with integrated magnetics (i.e. wirewound components) capable of meeting the high performance needs of today's telecommunications and networking applications.
